REVIEW OF THE YEAR 2010

Hi all,

balance 2010 is quite positive, even if no had great discoveries in length in my research. (Avalon crushed the other clubs on that side).

There have been many days of prospecting. And who says
surveys, said discoveries.
I will not list them but they are dozens of caves that were found. The Bourdon
hole and the hole of ants are my best finds. Why? Well read below.

Rudi prospects after the caves.

There were some guides.
Camp patro, guides to the park on days Furfooz discoveries and also during the night bats.

JB and activity patro.

There were these two discoveries of prehistoric caves concealing material.
I was very happy to have found the first bones in Neolithic hole Bourdon.
I was even happier when the discovery of a second cave containing Neolithic remains in the hole of the Ants.
The archaeological department of the province came directly effect the rescue of this material.
Michel Toussaint, anthropologist and Bibiche technician came to perform these searches.

Bibiche at the entrance of the Bumblebee.

Neolithic skull.

Rudi hole before the ants.

Some Neolithic bones. Rudi and Bibiche.

There have been many désobs hole at Mammoth, the hole of Chance, the hole in the block, the hole of the Ivies, the cave Désobeur, etc. ...

Désob the hole of Chance.

There was the visit of the Balm of Angels as part of my job with Jean-Jacques and Hugh, 2 very nice of cavers MASC Montelimar.

The group at the entrance of the Baume des Anges.

There have been numerous visits of caves known and less known.
visits during open houses.
The beautiful exhibition on Neanderthal man.
Etc ...

Tom and Rudi at the exit of the caves of Han.

Heritage Days at the Grotto Scladina.

Expo Neanderthal man.

But finally we had the pleasure to have shared lots of activities with lots of interesting people and that's the main thing. People like

Bibiche, Michel Toussaint, Rudi, Fred, Michel Pichel, JB, Mark, Tom, Yves, Jean-Pierre, Francois, Michel Timperman, the Cascade guys, and sorry if I have forgotten, and what was a real pleasure to have been known and in some cases (thank you nasty squeezes) be on your side.

Roll on 2011, hoping it will be for me and for you, as if not more interesting than the year 2010.

I think if you want to succeed in finding a great dévelloppement, restrictions sites and focus on one or the other but with perseverance.

HAPPY NEW YEAR 2011.

Dsobeur

Can A Dog Catch Human Herpes

MICHELTROUVETOUT TIPS: THE LAMP LED.

Hello,

caving is also the technical and wits.

Micheltrouvetout aka Professor Michel Pichel, will from time to time we present inventions, adaptations, modifications, basically all things that can engage the world of caving.

Micheltrouvetout.

This time, it gives us a way to mount an LED 1V in a conventional lamp.
Thanks to him.
Tip: You can click on the diagrams to see them larger.

Let him speak.

Replace traditional incandescent light by an LED-type "L UXEON " is not complicated. One parameter, however, not neglect, it is the supply voltage and the rated current, under penalty of destruction + or - fast this LED.

For the first parameter we will choose a voltage between 4.5 V and 6 V, allowing the use of 4 batteries of 1.2 V / 2700 mAh connected in series, or the good old 4-cell battery , 5v, or rechargeable 6v. The first 2 solutions that can be directly incorporated into a cordless headset for ~ 7 hours, for minimal weight.

As the current regulation, it will be ensured by an electronic system simple, reliable, cheap and here is the schematic diagram.

The practical realization is done by making a small circuit board, which will take place on the 5 components, the transistor being turned down on the circuit for reducing congestion.

· Drill holes diameter 0.8 mmpour components and 3.5 mm mounting holes

· Mount and solder these components on the circuit (follow the directions)

· son four times for solder connection to feeding the circuit, and led to the latter

· meet the LED and the circuit by 2 M3 screws / 20mm long, separated by a spacer of 6 to 8 mm where a space between the 2 pieces, it is necessary to enable the LED evacuate its rear calories (radiator)

· ; son going to solder the LED, anode (+) and cathode (note polarity) on the LED anode is marked by a dot

· block well done is then mounted in the lamp, after clearing inside this one its bulb and its plug heater, setting taking place by 2 screws, you of believing too long

· enlarge the hole of the old bulb in the reflector to allow transition to LED

· son solder connecting power to the circuit via the switch (again observe polarity)

And unless error or bad welds that must operate from 1 st blow. This assembly has already been proven on many items

The actual size of the printed circuit seen from solder side

is not the correct scale on this blog.

Friendship to all cave and the light be with you. If other explanations you find useful, you can contact me on my email address

pichelmic@gmail.com

PS : resistance of 220 ohm can be replaced by a transistor mounted TEC current generator (see diagram) A BF245 will do.

Materials needed

1 resistance 1, 8 ohm ; 2 screws M3/20mm long

a 220 ohm resistor ; 4 nuts M3

a BD137 transistor or equivalent ; 2 spacers 6 to 8 mm high

2 diodes 1N4148 a piece of single sided CI

LUXEON 1 1 W

                                                                  Pichel M


That there is more to go to practice.
A big thank you to Michel Pichel for giving us this information very interesting.

On the eve of Christmas, I wish you a Merry Christmas will probably be very Dash (I meant whiter than white).

Dsobeur.

A little link for great photos of arrivals at Avalon on the net recently, it has nothing to do with the subject but they are so beautiful.: http://www.scavalon.be/webalbums/index . html

Why Do Scorpio Men Vanish

REPRODUCTIVE stalagmites (minimum age 18)

Hello,

first, before talking about this very interesting, I'll introduce the world's foremost expert who has studied for over 40 years breeding stalagmites.
This is the distinguished professor Bibichol, a specialist in gynecology underground applied.
He has visited countless caves and all projects were successful, none have failed. Here is Professor

:

Professor Bibichol.

A tip, click on the photos, they will appear larger.

Professor Bibichol uses a very sophisticated equipment for samples taken underground.

Mr Rudiol and Professor Bibichol.

Mr. Rudiol and Professor Bibichol and hose used to collect.

descend underground to accompany Professor Bibichol.
It begins by showing us the collection of stalagmitozoïdes. He will need a big pipe that can be seen in top photo.

Some stalagmitozoïdes.

After removing them, Professor Bibichol explains the difference between a stalactite and a stalagmite male female.

Indeed, we must know that the stalagmites have sex.

how to see the difference? Well it's very simple dixit Professor Bibichol, just to look.

stalagmites females.

A stalagmite male.

Now that we've seen the difference, Professor Bibichol talks about the mistakes of nature in the sexual domain. We're not talking about large deviations, or sado-macho, but many features standard that are encountered in everyday life.

Homosexuality.

forced marriages.

Attempt white wedding.

Swinger.

Refusal. This is called hitting a bone.

The woman, the mistress and the husband.

Well, there are many other cases but Professor Bibichol had too much time to spend with us.

Seriously, next time, we will address the reproduction of stalactites. Other important issues: homosexuality among proteas, how to recognize a bat a mouse not bald sexuality to Earth-etc ...

A big thank you to Professor Bibichol that gives us the final word: "Get out of the caves covered mainly s' it's raining outside. "
If you want to contact the professor Bibichol, here's contact information: Bibichol Philippe, 69 rue du Fantasy 6969 Band-in-Condroz.

All photos were taken at the Bear Pit. (Thank you Cascade club for the visit).

No photos have been modified, it is Mother Nature that has been photographed.

Click the images to see larger.

A +

Idea and assembling Dsobeur (aka JC)

Can We Get Impetigo From Cats

VISIT TO BEAR THE PIT TO THE ROCHEFORT December 12

Hi all,

this Sunday, December 12 Geert and Stijn club caving Cascade, invited us to visit this beautiful cave.

Present: Geert, Stijn Club Cascade. Rudi, Yves and Bibiche of SCIG. And finally, JC independent.

Rendezvous was taken at Rudi Furfooz for cup of coffee.

Bibiche Stijn and deep in conversation.

The descent into the scree.

Bibiche gains strength, Geert takes notes.

eaten enough, come see these wonders.

Thanks to Geert and Stijn Cascade Club for showing us this underground treasure.

This fossil gallery is beautiful and congratulations on this discovery.

After this visit, and an attempt to visit the party lower, too close to myself, we surfaced.

Bibiche, Stijn and Geert went désober near the terminal sump.

What to say?
This cave is superb.
Protection is maximum (at the entrance gate, protected and hyper trail markup simple and efficient) that brief happiness, especially with the guidance of these two cavers very nice.
You've earned this wonderful discovery.

A +

Dsobeur

link with the blog caving club Cascade: http://sc-cascade.blogspot.com/2010/12/weekend-vol-afwisseling.html

The link to the blog of the club String: http://speleodinant.blogspot.com/2010/12/la-fosse-aux-ours.html
